Aluminium Boxen Edelstahl box
Aluminum Boxes Stainless Steel Box

Aluminium Box ungelocht
Aluminum Box non perforated

ER815.730 ER815.830 ER815.840 ER715.130 ER715.140 ER715.150
außen
outside 180 x 75 x 36 mm 190 x 95 x 36 mm 190 x 95 x 46 mm 220 x 105 x 36 mm 220 x 105 x 46 mm 220 x 105 x 56 mm Edelstahl Box ungelocht
innen 178 x 73 x 33 mm 188 x 93 x 33 mm 188 x 93 x 43 mm 218 x 103 x 33 mm 218 x 103 x 43 mm 218 x 103 x 53 mm Stainless Steel Box non perforated
inside

ES815.730 ES815.830 ES715.130 ES715.150
außen
outside 185 x 75 x 33 mm 195 x 95 x 33 mm 225 x 105 x 33 mm 225 x 105 x 53 mm
innen 182 x 72 x 30 mm 192 x 92 x 30 mm 222 x 102 x 30 mm 222 x 102 x 50 mm
inside

Aluminium Box ungelocht
Aluminum Box non perforated

ER915.530 ER815.520 ER815.330 ER715.550 ER715.560
außen
outside 58 x 48 x 28 mm 108 x 38 x 18 mm 138 x 58 x 28 mm 258 x 108 x 48 mm 258 x 158 x 58 mm
innen 55 x 45 x 25 mm 255 x 105 x 45 mm 255 x 155 x 55 mm
inside 105 x 35 x 15 mm 135 x 55 x 25 mm

Achtung! Kein Filter
Attention! No filter

Edelstahl Box gelocht
Stainless Steel Box perforated
Achtung! Kein Filter
Attention! No filter
ES810.730 ES810.830 ES710.130 ES710.150
außen
Aluminium Box gelocht outside 185 x 75 x 33 mm 195 x 95 x 33 mm 225 x 105 x 33 mm 225 x 105 x 53 mm
innen
Aluminum Box perforated inside 182 x 72 x 30 mm 192 x 92 x 30 mm 222 x 102 x 30 mm 222 x 102 x 50 mm

ER810.730 ER810.830 ER710.130 ER710.150
außen
outside 180 x 75 x 36 mm 190 x 95 x 36 mm 220 x 105 x 36 mm 220 x 105 x 56 mm
innen 178 x 73 x 33 mm
54 inside 188 x 93 x 33 mm 218 x 103 x 33 mm 218 x 103 x 53 mm 55
