8 Quality monitoring

Batch control - H₂O₂ indicator (plasma)
REF pack. unit

92-08102 colour change: from pink to yellow 1 box
100 strips / box, with test tube
for H₂O₂ sterilization (plasma)
self-adhesive

Batch control - FO indicator - class 4

92-08006 Indicator for steam-formaldehyde sterilization; 1 box
colour change depends on formaldehyde
concentration, exposure time and operating
temperature. Size of individual indicator: 6 x 74
mm, single self-adhesive. Test strips supplied
make it easier to evaluate the indicator after
sterilization. Colour change from beige to violet.

200 strips / box, with test tube
for FO sterilization

Batch control - Three-Phase Sequential Indicator steam indicator - class 5

92-08026 The blue indicator changes to black when exposed 1 box
to steam but this change does not ensure the
sterilization process' efficiency (UNSAFE). The pink
indicator changes to black to obtain the stated
values of the critical variables for class 5
indicators. These values are obtained when the
sterilizer is able to heat the steam at 134 ºC for 3.5
minutes or 15 minutes at 121 ºC. This situation is
named OK. Longer exposure times or higher
temperatures can be determined when the green
indicator changes to dark brown up to black. This
situation is named OPTIMUM.

250 pcs. / box
for steam sterilization
sterilizing program: 134 °C / 3.5 min. | 121 °C / 15
min.
